Ultrasonic Welding Wire Splicing Heat Shrinking Machine RSM-HSM-02

0.00
0.00
Quantity:
(Inventory: 1000)
Buy now
Add to cart

Description
Feature
  • Faster and more stable heat shrink efficiency by infrared light wave heating.
  • Labor saving. Automatic starting after wire loading and automatic releasing after heat shrinking is completed.
  • Compact design that can be directly matched with the ultrasonic welding station.
  • With MES ports, the machine can realize digital docking with the factory's system to facilitate improving productivity and optimizing resource utilization.

Specification
Model RSM-HSM-02
Application
 		Shrinking of wire splicing part by ultrasonic welding/crimping(on production line)
Tube  Length

Max. 80mm

Tube  O.D.
 		Max. 25mm
Temperature Range
 Max. 600℃
Heating Method Infrared light wave
Temperature Control
 		PID
Temperature Controller
 		2 sets
Heater Cover Material
 		304 stainless steel
Operation
Button+touch screen
Interface 1 USB
Interface 2
 Ethernet Port: Supports Modbus TCP Communication Protocol
Air Source
 0.4-0.6Mpa
Voltage AC 220V(single phase)
Current
 6A
Power
 1.3KW
Dimension
 L480mm×W270mm×H370mm

PDF Specification Download
